How do you change the color of a drawing in Solidworks?
Click Options (Standard toolbar) or Tools > Options. On the Document Properties tab, click Model Display. Under Model / feature colors, select Shading. Click Edit and select a color from the Color palette or click Define Custom Colors and define a color of a new shade or hue.
How do I fill a sketch with color in Solidworks?
The default color of the solid fill is black. You can change the color of the fill by selecting the area hatch in the graphics area and clicking Line Color on the Line Format toolbar (except in section views). Select a crosshatch pattern from the Pattern list.
How do you change the color of a drawing?
You can change the color of a drawing (non-transparent areas) to another color. On the [Layer] palette, select the layer that you want to change the color of. Use a color palette to select the color you want to change to, then use the [Edit] menu > [Change color of line to drawing] to change the color.
Why are my dimensions GREY in Solidworks?
SolidWorks has many default colors for different types of dimensions. On drawings, the two main types of dimensions are inserted (driving) and non inserted (driven). … When this mode is turned on, the user gets their colors right for other lines, but dimensions appear as both black and grey.
How do I change the hatch pattern in SolidWorks?
Also know, how do you change the color of a hatch in Solidworks? You can change the color of the fill by selecting the area hatch in the graphics area and clicking Line Color on the Line Format toolbar (except in section views). Select a crosshatch pattern from the Pattern list.
How do I fill an area in SolidWorks?
To create a filled surface, click Filled Surface on the Surfaces toolbar, or click Insert > Surface > Fill, set the PropertyManager options, and click OK .
How do you fill a pattern in SolidWorks?
To create a fill pattern, click Fill Pattern (Features toolbar) or Insert > Pattern/Mirror > Fill Pattern, set the PropertyManager options, and click . Parameters control the pattern layout. You can create a sheet metal perforation-style pattern, or a pattern of concentric shapes typically used to enhance aesthetics.
How do you change the color of a face in SolidWorks?
On the Document Properties tab, click Model Display. Under Model / feature colors, select Shading. Click Edit and select a color from the Color palette or click Define Custom Colors and define a color of a new shade or hue.
How do you thicken sketch lines in Solidworks?
You can select the line thickness icon and you will get a drop down list of the 8 thicknesses available and a 9th option for a custom thickness. Once you click off of the drawing you should notice the change in thickness. This is the quick and dirty way of changing the line thickness.
How do I color text in Solidworks?
To set system colors: Click Options (Standard toolbar) or Tools > Options, and select Colors.
How do you make a drawing layer?
The drop-down list is showing available layers to make active and the icon next to the list is the Layer Properties. The Layer Property dialog box is where all the information is stored and managed. To create a layer, simply click the New button on the right side. This will create a new row in the layers list.
How do I rotate a layer in Solidworks?
Creating SOLIDWORKS Layers To show the layers tab go to Tools > Customize… > Toolbars TAB and check Layer. From there, select the Layer Properties button and the Layers dialogue window will pop up as seen in the image below.
Where is the command manager in Solidworks?
To access the CommandManager: Click Tools > Customize. On the Toolbars tab, select Enable CommandManager. Click OK.
How do you change the color of a vector line?
You can also change the color by going to Layer property > Layer color and change all the layer color at once.
Why are my dimensions GREY in Catia?
If your options are on default dimension colors gray means non assosiative dimensions. Dimension does not have 3D element reference. On what level you are running CATIA? In V5R7 dimensions were gray when dimensioning drawing elements generated from mirrored 3D elements.
