Can you flip a part in Solidworks?
In a part, click Mirror (Features toolbar) or Insert > Pattern/Mirror > Mirror. See Mirroring Features. Create an opposite-hand version of a part. In a part, select a face or plane to mirror about, and then click Insert > Mirror Part.
How do you rotate an object in Solidworks without a mouse?
Press the arrow keys. Hold down Shift to rotate in 90° increments. Click Rotate View or View, Modify, Rotate; select a vertex, edge, or face; then drag the pointer.
Can you mirror a sketch in Solidworks?
Mirroring Sketch Entities as You Sketch Them (Sketch toolbar) or Tools > Sketch Tools > Dynamic Mirror . Symmetry symbols appear at both ends of the line or edge. Create the sketch entities that you want to mirror. The entities are mirrored as you sketch them.
How do you flip the origin in Solidworks?
To change both the sketch and orientation: Click in X-axis or Y-axis, and select a line to change the orientation of the sketch origin. You can select internal or external sketch entities as references to define both the orientation and the location along the X or Y axis.
How do you rotate an object 90 degrees in Solidworks?
Click Rotate View (View toolbar) or View > Modify > Rotate then drag the pointer . Drag with the middle mouse button. Press the arrow keys. Hold down Shift to rotate in 90° increments.
How do I rotate my trackpad?
Rotate: Move two fingers around each other on the trackpad to rotate an image. Swipe between pages: Swipe two fingers left or right to show the previous or next page.
How do I rotate a part in Solidworks assembly?
Click Rotate Component (Assembly toolbar) or Tools > Component > Rotate. The Rotate Component PropertyManager appears, and the pointer changes to . Select one or more components in the graphics area. Select a component and drag in any direction.
Why is mirror part greyed out?
If you see that the Mirror Part command is greyed out that is because you should pre-select the mirror face or plane. The Material checkbox in the Mirror Components PropertyManager is selected by default and lets you propagate the material of the mirrored part from the parent part.
How do I change the default plane in Solidworks?
Now press the spacebar once again and click the update standard view command. This will prompt you to select the Standard View you would like to assign the current view to. Select the standard view you would like associated with the current screen view, in our case the Front Plane.
What does dissolve feature do in Solidworks?
You can dissolve subassemblies into individual components, thereby moving the components up one level in the assembly hierarchy.
Where is the FeatureManager design tree in Solidworks?
The FeatureManager design tree on the left side of the SOLIDWORKS window provides an outline view of the active part, assembly, or drawing. This makes it easy to see how the model or assembly was constructed or to examine the various sheets and views in a drawing.
How do I change the mouse settings in Solidworks?
To set the number of mouse gestures in the mouse gesture guide, with a document open, click Tools > Customize. On the Mouse Gestures tab, select the number of mouse gesture. You can also customize the mouse gesture assignments through a visual drag-and-drop user interface.
How do you lock rotation in Solidworks?
In the PropertyManager, select Lock rotation and click . To lock rotation on all concentric mates in an assembly, in the FeatureManager design tree, right-click the Mates folder and click Lock Concentric Rotation.
Why are my touchpad gestures not working?
Solution. Uninstall Synaptics related application from Control Panel –> Programs and features. Go to Device Manager and uninstall similar drivers then shut down PC. … Try reinstalling the touchpad driver from Synaptics Windows 10 touchpad driver and reboot.
Does Apple trackpad work with Windows 10?
As we all know, Apple Magic Trackpad is a good companion to Apple Products like iMac, Mac mini and iPad. In fact, Apple Magic Trackpad 2 can also be used on Windows 10, and it supports almost all the gestures available on macOS.
