How do you delete a dimension line in Solidworks?
To remove a dimension from a drawing: Select a dimension and press Delete. Be careful not to delete any dimension that has a reference, such as one used in a note. Search ‘Deleting Dimensions’ in the SOLIDWORKS Knowledge Base.
How do you show sketch lines in Solidworks drawing?
To show a sketch in a drawing: Right-click the sketch in the FeatureManager design tree and select Show. The sketch entities highlight in the graphics area when you point over the sketch name in the FeatureManager design tree.
How do you hide all sketches in Solidworks?
To hide all types in the current document: Click View > Hide/Show > Hide All Types. After you select Hide All Types, you cannot show any hidden items until you clear Hide All Types.
How do I show all dimensions in a Solidworks drawing?
In SOLIDWORKS, it has always been very easy to show the dimensions for a feature: just double-click on the feature and presto: all the dimensions for that feature are shown. This makes it fantastically easy to edit dimensions without having to edit the sketch or modify the feature in the feature tree.
How do I change the size of a drawing in Solidworks?
To change a dimension: Double-click a dimension. The Modify dialog box appears. Change the dimension value with the arrows, thumbwheel , mouse wheel, or by typing in the dimension box.
To bring back any hidden dimension or annotation in your drawing, you’ll need to activate the Hide/Show Annotation command found under View > Hide/Show > Annotations. First, let’s hide some dimensions. If you select one or more dimensions, you can Right Click on a dimension and select Hide.
What is extension line?
Extension lines continue or extend from the surface of the object and establish the size of the dimension. They do not touch the object lines and extend slightly past the dimension line. Extension lines provide a means of displaying a measurement without placing the dimension on the part.
What is long break line?
Long break lines are thin solid lines that have zigzags to indicate a break. Short break lines are thick, wavy solid lines that are drawn freehand.
A hidden line, also known as a hidden object line is a medium weight line, made of short dashes about 1/8” long with 1/16”gaps, to show edges, surfaces and corners which cannot be seen. Sometimes they are used to make a drawing easier to understand. Often they are omitted in an isometric view.
Why can’t ti delete dimensions solidworks?
To delete a SOLIDWORKS Sketch Dimension you typically select the dimension and hit Delete. To edit the value of the dimension you would double-click on the value to open the Modify dialog. … But this doesn’t allow the dimension to be deleted.
What is Instant 2D solidworks?
Instant 2D (introduced in SOLIDWORKS 2016) The Instant 2D is a sketch feature that allows you to quickly modify your dimensions in a more organic way, than the standard “Modify box. … Just left click and hold on the edge of the dimension arrow and you can drag the dimension into place.
How do you hide sketch lines?
To hide a sketch in a drawing, right-click the sketch in the graphics area or in the FeatureManager design tree and select Hide.
How do you show dimensions in a drawing?
You can specify that dimensions marked for drawings be inserted automatically into new drawing views. Go to Tools > Options and in the Document Properties tab, click Detailing. Select Dimensions marked for drawing under Auto insert on view creation.
To show dimension names: Click View > Hide/Show > Dimension Names or Hide/Show Items > View Dimension Names (Heads-up View toolbar).
Why are dimensions GREY in SolidWorks?
SolidWorks has many default colors for different types of dimensions. On drawings, the two main types of dimensions are inserted (driving) and non inserted (driven). … When this mode is turned on, the user gets their colors right for other lines, but dimensions appear as both black and grey.
