how to highlight text in solidworks drawing ?

Contents

How do you highlight a line in Solidworks?

In drawings, edges dynamically highlight as thin phantom lines, and edges of faces dynamically highlight as thin dashed lines. To control dynamic highlighting, click Tools > Options > System Options > Display and select or clear Dynamic highlight from graphics view.

How do you show colors in Solidworks drawing?

To show model colors, click Tools > Options > Document Properties > Detailing. Select Use model color for HLR/HLV in drawings. Search ‘Show Model Colors in Drawings’ in the SOLIDWORKS Knowledge Base.

What is dynamic highlight in SolidWorks?

Dynamic Highlighting When you move the pointer over an edge or a face, edges highlight as thick solid lines; edges of faces highlight as thin solid lines. … Edges highlight as thick solid lines.

What does large assembly mode do in Solidworks?

Large Assembly Mode is a collection of system settings that improves the performance of assemblies. You can turn on Large Assembly Mode at any time. You can also set a threshold for the number of components to automatically open the assembly in Large Assembly Mode when that threshold is reached.

What are breadcrumbs in Solidworks?

Selection breadcrumbs are a context-based view of the current selection. They show related elements in the hierarchical tree for parts and assemblies. You can select an item in the graphics area and refine that selection through the context-based representation of the item by using breadcrumbs.

How do I color text in SolidWorks?

To set system colors: Click Options (Standard toolbar) or Tools > Options, and select Colors.

INTERESTING:   5 Ways to Speed ​​Up Product Creation

How do I add color to a part in SolidWorks?

Click Options (Standard toolbar) or Tools > Options. On the Document Properties tab, click Model Display. Under Model / feature colors, select Shading. Click Edit and select a color from the Color palette or click Define Custom Colors and define a color of a new shade or hue.

How do you add color in SolidWorks?

Scroll down to Drawings > Paper Color and select it. Click edit to open the dialog box that lets you select the color. You can choose predefined colors, or create your own from the color plot and by entering the RGB information.

How do I change the orientation of a drawing in Solidworks?

Click View Orientation (View toolbar). Click View > Modify > Orientation. Press the Space Bar. Right-click in a drawing sheet and select Zoom/Pan/Rotate > View Orientation.

How do you select all edges of face in Solidworks?

To select everything in the graphics area: Click Edit > Select All, or press Ctrl+A. To limit the selection to specific entities in a part, pre-select one or more entities in the graphics area. For example, pre-select an edge and a vertex to limit the selection to all edges and vertices.

What is lightweight mode solidworks?

You can load an assembly with its active components fully resolved or lightweight. Both parts and subassemblies can be lightweight. When a component is fully resolved, all its model data is loaded in memory. When a component is lightweight, only a subset of its model data is loaded in memory.

How do I turn off lightweight in Solidworks?

Thankfully, the solution is quite easy. Within SOLIDWORKS make the following changes: Tools -> Options -> System Options -> Performance: turn off “Automatically Load components lightweight.”

INTERESTING:   SOLIDWORKS Electrical Online Overview

How many entities can you choose to mate with an angle mate?

Click Mate (Assembly toolbar) or Insert > Mate. In the Mate PropertyManager, for Entities to Mate , select two entities in the graphics area or the flyout FeatureManager design tree. Under Standard Mates, click Angle and set the dimension.

How do I change the color of a layer in SolidWorks?

Using Layers to Change Colors This can be easily accomplished using layers. Using either the Line Format toolbar or the Layer toolbar, click Layer Properties. In the dialog box that appears, create a new layer and set the color of the layer to red. Click OK when finished.

Why are my dimensions GREY in SolidWorks?

SolidWorks has many default colors for different types of dimensions. On drawings, the two main types of dimensions are inserted (driving) and non inserted (driven). … When this mode is turned on, the user gets their colors right for other lines, but dimensions appear as both black and grey.
