How do you select a circle in Solidworks?
Shift-Select Hold down what I call in SOLIDWORKS, the magic key, which is shift. I’ll hold the shift key down then select the circle toward the inside that I want to snap to.
How do you select a center point in Solidworks?
Just go to Tools, Options. I typed “centerpoints” in the search box and then just select the option you want and it will take you right to it.
How do I wake up Center Point in Solidworks?
Select the top surface and use Sketch → Line. “Wake up” the center point again.
What is quick snaps in Solidworks?
Quick Snaps. The Quick Snaps tool makes it easier to select specific items in your sketch when adding geometry. You can define what you want to snap to and SOLIDWORKS filters out all other possible snaps.
What is rebuilding in Solidworks?
Rebuilds the model with changes. To rebuild the model: Click Rebuild (Standard toolbar) or Edit > Rebuild, or press Ctrl + B. Rebuilds only the features that changed since the last rebuild. To rebuild all features, press Ctrl + Q.
How do I repair a sketch in SolidWorks?
To open the Repair Sketch tool: Click Tools > Sketch Tools > Repair Sketch. Repair Sketch deletes these from the sketch.
Where can you find the centerline and midpoint line tools in Solidworks?
Click Midpoint Line (Sketch toolbar) or Tools > Sketch Entities > Midpoint Line. Search ‘Midpoint Line’ in the SOLIDWORKS Knowledge Base.
How do you highlight in Solidworks?
Items in the graphics area are highlighted when you select them, or dynamically highlighted when you move the pointer over them. You can set the colors for selected items, dynamic highlighting, and other user interface items in Tools > Options > System Options > Colors.
How do I turn on quick snaps in Solidworks?
You can enable Quick Snaps, regardless of whether Enable snapping or the Sketch Snap is selected under Options > System Options > Relations/Snaps . Double-click Quick Snaps on the toolbar to retain the snap capability for multiple instances of the same sketch entity, or until you select different Quick Snaps.
What does Ctrl Q Do in Solidworks?
Forced Rebuild (Ctrl+Q) This Forced Rebuild will also rebuild any views on a drawing which have sketch entities or require rebuilding. Often a Ctrl+Q can fix some issues which are persist through the standard rebuild.
Rebuilds all features in all configurations. Rebuilds all features in the top-level assembly. Forced rebuilds can take significantly more time, depending on model complexity. The Rebuild toolbar buttons are located on the Standard toolbar.
How do I turn off auto rebuild in Solidworks?
To turn off the option, right-click the assembly name at the top of the FeatureManager design tree, and clear Suspend Automatic Rebuild.
How do you center a rectangle in SolidWorks?
Click Center Rectangle from the Rectangle flyout tool or click on the Menu Bar as Tools>Sketch Entities>Center Rectangle. Click to place the center point of the rectangle in the Graphics area. Move the cursor in any direction and click to set the four edges of the rectangle. Click Ok.
What is large assembly mode in Solidworks?
Large Assembly Mode is a collection of system settings that improves the performance of assemblies. You can turn on Large Assembly Mode at any time. You can also set a threshold for the number of components to automatically open the assembly in Large Assembly Mode when that threshold is reached.
How do you make a subassembly flexible in Solidworks?
Making a Subassembly Flexible To make a subassembly flexible: Click a subassembly in the FeatureManager design tree and select Component Properties . In the dialog box, under Solve as, select Flexible, then click OK.
