How do I stretch a part in Solidworks?
In the PropertyManager, under Entities to Stretch, select sketch entities for Sketch item or annotations. and then click on the sketch to set a base point. Drag to stretch the sketch entities. When you release, the entities stretch to that point and the PropertyManager closes.
How do you revolve in Solidworks?
Create a sketch that contains one or more profiles and a centerline, line, or edge to use as the axis around which the feature revolves. Click one of the following revolve tools: Revolved Boss/Base (Features toolbar) or Insert > Boss/Base > Revolve. Revolved Cut (Features toolbar) or Insert > Cut > Revolve.
How do you make a four sided pyramid?
For the square pyramid, start with a square base. Use the length of a side to determine the size of your triangular sides. Cut each triangle with the edges equal to one side of the square. Join the sides to the base, then join the sides of each triangle to form the pyramid.
What are the two components necessary for creating a revolve feature?
There are two ways to created revolved features: from a sketch profile or from a primitive. The primitive shape creation commands create full revolutions only. They do not create surfaces or partial revolutions.
What is needed to revolve a feature?
About the Revolve Feature. A revolved section requires an axis of revolution that can be created either with the section or defined by selecting model geometry. Legacy revolved features that were defined using the Constant angle option are automatically converted to Variable.
Can you bend parts in Solidworks?
The sheet metal features appear in the FeatureManager design tree. To bend the sheet metal part, sketch lines on the part as shown. , or Insert > Sheet Metal > Sketched Bend . The part bends at the sketched lines.
What feature would you use to draw a cone in a 3d modeling software?
Creating a cone In SketchUp, you can create a cone by resizing a cylinder face or by extruding a triangle along a circular path with the Follow Me tool.
What is a 5 sided pyramid called?
In geometry, a pentagonal pyramid is a pyramid with a pentagonal base upon which are erected five triangular faces that meet at a point (the vertex). Like any pyramid, it is self-dual.
Is a pyramid 3 or 4 sides?
Despite what you may think about this ancient structure, the Great Pyramid is an eight-sided figure, not a four-sided figure. Each of the pyramid’s four side are evenly split from base to tip by very subtle concave indentations.
What angle is a pyramid?
How Steep? Each side of the Great Pyramid rises at an angle of 51.5 degrees to the top. Not only that, each of the sides are aligned almost exactly with true north, south, east, and west.
How do you make a pyramid in NX?
connect the point to the rectangle corners by four lines. then use bounded plane command to make four triangular and one rectangular flat surface enclosing the pyramid volume. then if you need a solid body you can use sew or combine.
Can we extrude the sketch in both direction yes or no?
To extrude in both directions from the sketch plane in the PropertyManager, under Direction 1, select Through All – Both Directions. To extrude as a thin feature, set the PropertyManager options in Thin Feature.
Click Extrude (2D to 3D toolbar), or click Tools > Sketch Tools > 2D to 3D > Extrude, and click in the graphics area to establish the direction of the extrusion.
How do you make a revolved boss in Solidworks?
To create a revolve feature: Create a sketch that contains one or more profiles and a centerline, line, or edge to use as the axis around which the feature revolves. Click one of the following revolve tools: Revolved Boss/Base (Features toolbar) or Insert > Boss/Base > Revolve.
How many sketches are required to create a simple swept feature?
3 Unlike an extruded feature, a swept feature requires a minimum of two sketches.
